Mouse Brain Gross Anatomy Atlas

[Part I Fixed Brain][Part II Fresh Brain]

1-4  5-8  9-12  13-14

Step5



DBA/2J
21 g

Keep working on the other side of the brain pull up both sides of the cortex that covering the hippocampus along the ventricle. Now you can see the dorsal part of the hippocampus. Separate the rest of the hippocampus from the cortex covering it along the surface of the hippocampus towards the ventral part of the hippocampus.
Step6



DBA/2J
21 g

Now you need to free the hippocampus from the surrounding tissue.
Step7



DBA/2J
21g

Here is the hippocampus picked out from the brain.
Step8



DBA/2J
21g

The rest of the brain that hippocampus has been taken off.
